Spring Wires

Nippon Seisen's spring wires are manufactured using strict quality assurance, and they are well-regarded by our customers due to the wires' consistent workability. Our originally developed steel grade gives them high strength, strong heat resistance and super non-magnetic properties, giving customers lots of added value.

Spring Wires

For Spring-Related Applications

Steel types
SUS304, SUS302, SUS304N1, SUS316, SUS631J1
Wire diameters 0.020mm - 12.00mm
Treatments 1/2H - H
Finishes NB (standard finish), EB (polished finish), UB (highly polished finish)
Coatings No coating, NF·NS·NP (Ni coating), RD (resin coating)
Standards JIS G4314, EN10270-3

Straightened Wires

Straightened Spring Wire

Straightened Spring Wire is a material, developed as the first of its type in the world by Nippon Seisen, which has undergone straightening processing. It has a great reputation in applications such as torsion springs, pins, and filigree.

Steel types SUS304
Wire diameters 0.2mm - 1.4mm
Treatments 1/2HT – 4/4HT
Finishes EB (polished finish), UB (highly polished finish)
Standards JIS G4314

For High Strength Applications

Nippon Seisen's high strength spring wire is well-loved, and is used in areas such as piano wire replacement, abbreviation of plating processes, compact applications, and weight-reduction applications.

Steel types NAS301H

* For more information, please contact us.

For Highly Nonmagnetic Applications

Typically, SUS316 is used for stainless steel springs requiring special nonmagnetic properties. However, for applications such as the latest precision electronic devices, precision electronic medical parts, needle detector, this is not enough protection against the influence of magnetic fields. Nippon Seisen's highly nonmagnetic spring wire will not be affected by magnetic fields in any area of use.

Steel types NAS106N, NASNM15N

* For more information, please contact us.

For Heat Resistant Applications

Depending on the type of steel selected, Nippon Seisen's heat resistant springs can continue to function as springs under all sorts of temperature levels (up to 750° Celsius). In addition, depending on the type of steel selected, new value can be created through possibilities such as decreasing cost or increasing corrosion resistance.

Steel types SUS631J1
INS307H, NAS316H1
NAS604PH
SUH660, NAS670HT
NAS520, NAS530
(~450° Celsius, standard steel type)
(~450° Celsius, low cost heat resistance)
(~500° Celsius, heat resistant, super corrosion resistant)
(~650° Celsius, super heat resistant spring)
(650 - 750° Celsius, super heat resistant alloy spring)

* For more information, please contact us.

For Easy Identification

真直線

Nippon Seisen's easy identification spring wires include brasscolor wire and black colored wire. They both have good reputations for their uses in situations such as telling apart wires with similar shapes and diameters, or where black is required (such as internal parts of a camera).

Finishes CU (brass color), VBNF (black color)

* Can be applied to any type of steel.
* For more information, please contact us.

Other Shapes

Other Shapes

Nippon Seisen can manufacture springs for any use into differently shaped wires, such as flat or squared wires. Differently shaped wires can help with reducing space requirements or increasing strength through their shape.

Shapes Round-edged flat wire, Square-edged flat wire, Squared wire

* For more information, please contact us.

For Hydrogen Resistant Applications

"Hydrogen embrittlement resistance" will be a keyword for high strength metals in the next-generation hydrogen-based society that will develop around fuel cells. Nippon Seisen has become the first in the world to develop a new steel type which can withstand use in a hydrogen environment.

For Copper Beryllium Alloy Replacement Applications

For Copper Beryllium Alloy Replacement Applications

With the increase in environmental issues, use of hazardous materials is becoming more and more restricted. Responding to these conditions, Nippon Seisen has developed a beryllium-free high strength conductive spring. The strength matches that of copper beryllium alloy, and its solder wettability is greatly increased.
